Rapid Deployment are certainly the buzz words in all Military Forces presently, the capability to rapidly establish an airborne infrastructure is an essential part of strategies laid down by Joint Armed Forces worldwide.
The Mobile Visual Control Room (MVCR) or Mobile Air Traffic Control Tower is an integral part of any Joint Armed Forces Aerospace Surveillance and Battle Space Management System. The requirement of an operational airbase is essential to all operations in-theatre very early in any conflict and therefore the equipment used must reflect the requirements of urgency and the possible lack of lifting equipment or specialised vehicles for deployment.

Rapid Deployable ATC Towers

The trailer mounted system is designd specifically for rapid and simple deployment.

The Mobile Air Traffic Control Systems ATC tower is transportable by C-130, C-17 and has undertaken live trials with Chinook helicopter, and can be deployed by 2-4 personnel in an hour. All equipment needed to deploy is carried within the unit and there is no additional lifting equipment necessary.
Mobile Air Traffic Control Systems designed their tower to be trailer mounted so that it can be towed by various unspecified vehicles and removes the single point of failure of a truck-mounted system.

Mobile Elevating Towers

The tower elevates to 7m operator seated height and allows for 3 operators plus 1 supervisor position. The internal fit is designed specifically to meet the precise operational requirements of the end user but be flexible in terms of upgrades and/or additional equipment requirements to cope with local operating conditions.

Features

Mobile Air Traffic Control Systems have specifically designed their mobile system for uncomplicated Rapid Deployment with a minimum of parts.
Whether it is to be used for military applications, a stand-by or disaster relief, it is important that the unit can be deployed quickly and efficiently.
The Systems all feature a new Automatic Levelling System and remotely controlled deployment that levels and deploys the cabin to full  height and locks it in position hydraulically in under 5 minutes.

• The system has been designed to be deployed by 2-4 men in under an hour.
• All equipment needed for deployment is stored within the cabin or trailer system – the unit is completely self contained.
• No need for any special lifting or handling equipment to deploy
• Towers can be run off mains or powered by a generator.
• The Cabin is trailer mounted for reliability, ease of use and flexibility – the cabin can be removed in 15 minutes.
• Multi-level towing positions to cope with variety of different towing vehicles.
• Robust heavy duty trailer system with EBS that automatically adjusts the air suspension to ensure the system remains level when being towed.
• The trailer has adjustable air suspension to increase or decrease ground clearance.
• Simple deployment – ONLY FOUR BOLTS in the entire deployment so less to lose and less FOD.
• C-130, C-17, IL-76 and Heavy Lift Helicopter transportable
• Tower has 3 operating heights, elevating to a maximum of 7m operator seated height.
• Up to 4 operator positions
• Cabins fitted with fully plug and play integrated systems comprising usually of military or commercial air to ground communications, voice switching and recording, meteorological reporting, navigational equipment and ground to ground communications to customer specification.
• 360 ° vision from all operator positions.
• LED lights throughout including the stairs
• High spec ATC double glazed glass.
• Dual Air Conditioning Units
• Ballistic protection and Bullet Proof Glass options
• Operators can safely evacuate the cabin in under 20 seconds unlike some towers that require an elevator.
• Tower meets all Safety Regulations including Working at Height and evacuation procedures.

All Terrain Truck Mounted ATC

MATC introduced their new 6x6 All Terrain Mobile Air Traffic Control Tower at the World ATM Congress in Madrid 4-6 March 2014.  Described as a “game changer in tactical military ATC operations” the 6 wheel drive Mercedes mounted system had a lot of interest. Designed in principal for Middle East and Asian operators, the unit is autonomous with an in-built generator, automatic levelling and an operator height of 7.5 metres and is delivered plug and play. It features an automatic tyre deflation and inflation system to cope with wheel slip on sand or wet conditions whilst maintaining a fast on-road speed enabling quick location and relocation. The cabin is the same as the trailer mounted unit.

Added to this MATC introduced a new Compact ATC Cabin that can be towed and positioned by any four wheel drive. This is aimed at smaller strips and airfields where elevation is not required, it is equipped to the same ATC standard as the other models and has an onboard generator and fuel tank.

UTILITY FLAME™ is THE heat source for field rations, field hygiene and survival. It is used by the armed forces of the United States and other NATO forces. It is the safe and more effective alternative to the flameless ration heater used for MRE. Unlike the old trioxane heat tabs and Esbit blocks, UTILITY FLAME™ is non-toxic, non-hazmat, smokeless and odorless. Ideal for whenever your forces need ‘fire in the field.’

Military Field Rations - UTILITY FLAME™

It is the safer and more effective alternative to the flameless ration heater used for MRE.

Military Survival Gear Fire Gel

In addition to heating field rations, UTILITY FLAME ™ provides a source for light and heat in any environment. Field survival often requires a soldier to start a fire under less than ideal conditions. Burning at over 700° C, UTILITY FLAME ™ will start a fire anywhere, anytime.

Field Hygiene and Sanitation

Hot water in the field for hygiene and sanitation is not always possible, but with UTILITY FLAME ™ the modern warfighter can have clean, safe water in minutes.

Soldiers Kit and Equipment - Portable Military Fire Gel

It is so safe that it is approved for unrestricted transport on military and commercial aircraft, since it is a stable, non-toxic, and non-hazardous material with a low flash point.

Fire Starter Gel

The UTILITY FLAME™ kit comes with an ultra light metal stove that creates a convection flow that funnels the heat where it’s needed. It fits standard issue canteen cups and pots weighing up to 1.3kg. It is perfect for all gel and solid fuel cookers including the Crusader Cooker and the Esbit Stove. Of course, the gel can be set directly on the ground or any other surface.

Fire Gel - UTILITY FLAME™

UTILITY FLAME™ is available in a 1.25 ounce packet and a re-sealable 6 ounce pouch. It can also be custom packaged to meet your specifications, including custom graphics to incorporate your information in your language.

In summary, UTILITY FLAME™ is light, inexpensive, safe to transport and use, and extremely versatile. It is an excellent addition to the soldiers’ kit, and makes a valuable gift to allies in the field.

•    Heats MRE entrees
•    Provides hot water for hygiene
•    Cooks indigenous foods
•    Purifies water
•    Boils water for hot beverages
•    Gives off high temperature flame for emergency sterilization
•    Does not evaporate, freeze or melt.
•    Burns hot (700°C).
•    Use in temperatures as low as -30°C and at elevations of 5,000+m.
•    Not explosive (high ignition/flash point of 151°C)
•    Zero vapor pressure
•    Unlimited shelf life
•    Water soluble — washes off with water
•    Smokeless, odorless, non-toxic, and non-hazmat. No transport restrictions
•    “Green” product. Byproducts are carbon dioxide, water, silica sand
•    NSN number and available in COTS.

UTILITY FLAME™ is manufactured in the USA and distributed by the SIL Group of Tampa, Florida. The SIL Group draws on a number of retired military leaders as consultants, including MG (Ret) Geoffrey Lambert, former commanding general, U.S. Army Special Forces Command (Airborne), Fort Bragg, N.C.

Alfred Kärcher GmbH & Co. KG was founded in 1935 and is today the world’s leading manufacturer of high-pressure cleaning equipment. The company employs 8,700 people and has more than 80 subsidiaries all over the world. The head office is located in the south of Germany, near Stuttgart.

With the aim to further optimise the company structure and its efficiency for the benefit of its customers all over the world, the former SGC Division (Sales Government Customers) has become as Kärcher Futuretech GmbH an independent company. Besides cleaning equipment Kärcher’s subsidiary Futuretech develops, manufactures, and markets products for the special needs of public customers, such as the armed forces, fire brigades, civil defence, disaster control and relief organisations.

Futuretech strives to be the world’s top performer in the area of peacekeeping and disaster relief with highly mobile, customised and compact system solutions. Innovative state-of-the-art systems and a full product range make Futuretech the world market leader in “Professional Systems for Peacekeepers”.

Together with our highly satisfied and inspiring customers, Futuretech develops and produces systems that help to solve the challenges of the future. The innovative Futuretech systems are developed together with the ministries of defence of the leading nations and their experts for world-wide missions: for the maintenance of peace and quick aid for the needy after a catastrophe.

Product Range of Futuretech:

CBRN Protection Systems

Futuretech is a worldwide leader in CBRN protection for both military and civilian applications. We provide a comprehensive system consisting of decontamination equipment including decontamination devices, modules and systems, and chemical, biological, radiological and nuclear (CBRN) decontamination agents. Prompt and effective decontamination of persons, tanks and other vehicles, air and watercraft, personal weapons, clothing and equipment as well as sensitive material ensure the ability of the concerned troop, civilian population, police, frontier guard, etc. to survive. According to the specific needs, Futuretech offers customer-designed solutions on platforms, trailers or in containers.

With the DRDS 1 (rescue and decontamination set for one person), Futuretech is proud to present the world’s first logical overall concept which not only makes the work of fire-fighters and first responders considerably easier, but above all enables patients to be rescued in a more human manner through professional decontamination.

Military Water Supply Systems

To fulfil the basic need for drinking water Futuretech has developed a range of mobile purification systems. These systems are able to desalinate sea and brackish water. They produce drinking water out of nearly any water quality without the need for chemicals. Even water from contaminated sources can be purified.

With its innovative solutions and continuous further developments in the area of mobile water supply, Futuretech has recently developed a fully automatic water bottling plant (WBP 1300) which produces and fills up to 26,000 PET bottles per day under hygienic conditions in the field. Several UV disinfection steps during the PET bottling process and sterile filtration of the incoming drinking water ensure best water quality.

Military Mobile Catering Systems

Futuretech as the mobile catering systems specialist designs, tests and produces future-oriented systems together with experts from all over the world. The systems are highly mobile and flexible in use and can be transported even to the most remote sites. Ranging from the individual module to the container kitchen, the Futuretech catering systems are designed for transport by road, sea and air.

The newly developed mobile compact kitchen KRR 50 E ensures high-quality catering everywhere, regardless of the available infrastructure, under field conditions, and can be set up in just 15 minutes. Three easy-to-carry functional boxes convert into a complete catering line in which a variety of delicious menus can be prepared for 50 persons using the most different cooking methods (stewing, frying, grilling and baking).

Military Field Camp Systems

Futuretech’s range of field camps are deployable military facilities which - after a short assembly time – provide living and working conditions similar to those in the soldier’s home country during an extended period of deployment abroad. Futuretech systems promote the well-being of soldiers and task forces and enhance their morale and motivation.

Futuretech offers a full product range with its modular structure. Components are sanitary facilities, catering systems, and laundry systems.
As an example, the Modular Air-transportable Field Camp (FLM) is designed to answer the needs of 150 people, but can also be broken down into 50 people units. The air-transportable field camps shall be used particularly for initial operations as well as NATO or EU missions of German forces.

Portable Aluminium Roadways, Runways and Helipads
for the Defence Industry

FAUN Trackway Limited, based on the Isle of Anglesey, North Wales, is the defence division of Europe’s number one municipal vehicle manufacturer, FAUN KIRCHHOFF GRUPPE.

FAUN Trackway designs and manufactures a range of high-quality portable access systems for use in military and civilian disaster and emergency relief operations at its internationally accredited production facilities in the UK.

Unbeaten in all trials, FAUN Trackway’s products are used in more than 40 different militaries worldwide. FAUN Trackway products were initially designed and developed for the UK Ministry of Defence (MoD). Now its products are widely used in a variety of humanitarian and disaster relief operations, where rapid access to cut-off areas is essential.

The utility and mining industries use FAUN Trackway products to explore areas where access would otherwise be impossible. FAUN Trackway employs a team of highly skilled engineers dedicated to exploring new product designs and working alongside future and existing customers to create bespoke solutions to their problems.

Portable Military Roadways

Heavy Ground Mobility System (HGMS)
and Medium Ground Mobility System (MGMS)

FAUN Trackway produces two complete portable roadways solutions: Heavy Ground Mobility System (HGMS) and Medium Ground Mobility System (MGMS)

The Trackway® on the HGMS has full capability of carrying loads of up MLC 150 dependent on ground conditions, and has approval for indefinite use with M150 loaded vehicles at ground condition of  3% California Bearing Ratio (CBR).

50m of M150 Trackway® can be deployed in under 10 minutes.

HGMS allows vehicles to move with ease over difficult terrain conditions such as sand, snow, mud, swamp and ice helping to speed mobility and protect assets.

HGMS can also carry an additional 50m TRACKWAY®, towed behind the chassis on a trailer. This enables longer roadways to be laid quickly and connected easily.

FAUN Trackway’s Medium Ground Mobility System (MGMS) consists of the same key elements as HGMS. MGMS comprises 32-metre lengths and can be deployed in under 6 minutes by two people.

Like all FAUN Trackway products, MGMS is unbeaten in all trials and can withstand repeated loads of up to 30 tonnes. It is most appropriate for vehicles with pneumatic tyres and can also be used with JCB and specialist dispenser for beach landings.

Temporary Runways and Helipads

FAUN Trackway has three aluminium panelling designs suitable to create Forward Operating Pads for Vertical Take Off and Landing (VTOL) aircraft – the Helicopter Landing Mat.

They are designed to alleviate brown out while marking out a clear landing area.

Aircraft Landing Mat (ALM)

FAUN Trackway’s Aircraft Landing Mat (ALM) is a rapidly deployable expedient runway for longer term temporary installations.

Rapid Runway Repair (RRR)

FAUN Trackway’s Rapid Runway Repair (RRR) mats enable critical sections of an airfield to be repaired in order for flying operations to be resumed following an enemy attack.

Bespoke Engineering Solutions

Trackway® continues to invest heavily into the research and development of new products.
FAUN Trackway’s team of engineers work close with key partners such as the UK’s Ministry of Defence – to which it is a prime contractor – as well as leading military institutions such as the U.S military’s Engineer Research and Development Centre (ERDC), in order to develop bespoke solutions to individual problems.

CONTAINEX - a company of the WALTER Group - is the leading European supplier
for containers and mobile space systems. Industry, trade and commerce as well as local authorities and aid organisations benefit from the high product quality and the attractive price-performance ratio of the CONTAINEX space systems.

Our large depot network all over Europe and the logistical support of our parent company LKW WALTER, the leading European road transport organisation, guarantee prompt delivery to your location of usage.

Military Office Cabins

In the sizes from 10' (3m) to 30' (9m) in many layout options available. The modular construction allows a large number of configuration possibilities. You can use the cabins individually, or optionally assemble them next or on top of each other. By leaving out wall panels and installing partition walls any room sizes can be created. Due to the modular construction the CONTAINEX space solution is expandable at any time. Additional rooms can be created quickly and easily. Changes to existing buildings at a later stage can be done without any problem.

• A robust construction is guaranteed by the massive steel frame.
• Easily interchangeable wall panels with galvanised steel skins provide for an excellent appearance over years.
• High-quality heat and sound insulation guarantee comfort.
• Double glazed PVC windows with integrated roller shutters are exceptionally user-friendly.
• The external dimensions of the CTX cabins match the ISO standard and can therefore be transported easily.

Office cabins can also be supplied as flat packed Transpack cabins.

• Up to 8 cabins can be loaded on a truck.
• Cost saving due to D.I.Y. assembly.
• Quick and easy erection with standard tools.

Military Sanitary and WC Cabins

• Quick installation on site
• Promptly usable
• Solid steel construction
• Complete and comfortable equipment
• Fresh water instead of chemicals

CTX sanitary and WC cabins can be supplied in numerous high-quality layout options.

All configurations are characterised by extreme user-friendliness. Sanitary and WC cabins can certainly be combined with office cabins.

Military Storage Containers

• Storage options in many ways
• Optimum security
• Depots all over Europe
• Containers in many dimensions
• Available also in a set

Additional security and electrical fittings can be supplied!

Military Shipping Containers

CTX shipping containers are ideal for overseas transports!

Whether new or second hand, our shipping containers can be used as cost-saving export packaging. The containers have a CSC plate and are promptly available all over Europe.

Was founded in 1946 and has over 60 years experience in the manufacture and supply of a wide range of Defence and Security Equipment for Governments, Defence Forces, Security Forces, NGOs and commercial customers all over the world. Franklin manufactures shelter tents for accommodation, command posts and field hospitals; CBRN tent liners; webbing and PLCE; camp beds and mosquito nets; camouflage nets and clothing and equipment for emergency relief and humanitarian aid.

The company has expanded but J & S Franklin remains a compact family-run business which guarantees reliability, continuity and confidentiality.

J & S Franklin has a reputation for delivering high quality products to our many customers and has successfully sought to understand and satisfy their precise requirements.

Experienced executives provide professional advice and frequent in-country visits with the support of highly trained and skilled staff and consultants.

J & S Franklin is a major Contractor to the UK Ministry of Defence as well the preferred supplier to many overseas Governments, Police Forces, International Agencies and the United Nations. It operates a quality management system assessed to the quality system standard BS EN ISO 9001:2008

J & S Franklin Manufacture a Wide Range of Equipment:

Military Tents and Shelters

Standard shelters and specialised units tailored for specific requirements

The GP shelter family are the mainstay of the UK MoD Improved Tented Camp (ITC) system and are extensively deployed in Iraq and Afghanistan. They have a lightweight tubular frame providing high strength and stability. Being of modular design, they can be extended and joined for field hospitals or shelter complex.

Franklin also makes the shelters for the Operational Field Catering System (OFCS) and more than 1400 have now been supplied to the UK MoD. The OFCS Shelter is based on the standard 12’ x 12’ shelter tent, modified with heat-resistant fabrics and cut-outs in the roof for the OFCS cooker chimneys.

CBRN Equipment for collective and personal protection - CBRN protective liners are made of CBRN-resistant materials and Franklin manufactures a range of liners that can be designed to interface with various vehicles and containers.

Camp Equipment - Camp Cots, Cot mounted and free standing Mosquito Nets and folding chairs have all been supplied to MoD.

Camouflage Nets and Systems - Individual, IRR, Thermal

Webbing and Personal Equipment - Rucksacks and Travel Bags are currently being made as well as the shelter sheet in both woodland and desert camouflage patterns.

J & S Franklin is often the chosen partner to give a complete turnkey service, using its extensive facilities to deliver a Single Source Supply; combining rapid response, experience and confidentiality to provide economical, secure and effective solutions, on a global basis. We are experts in the provision of specialised turnkey operations, drawing together the many components needed to satisfy our customers requirements; the latest and most suitable equipment, experienced support personnel, full training packages, secure packaging and delivery services and, when necessary, finance, counter-trade and insurance.

DefenCell™

In association with Terram J & S Franklin can also offer DefenCell™ which is an expeditionary earth filled barrier system to allow structures to be constructed from locally available compactable materials to allow the quick assembly of defensive and protective structures.

Franklin is also supplying the MoD with a range of full-size inflatable decoy targets for training. The inflatables offer realistic visual, radar and thermal image signatures and are rapidly deployed in less than 15 minutes and include Scud missile and launcher, T72 tanks and SA15/19 vehicles.

Soft Walled Military Shelter Systems and Technology

DHS Systems International is a subsidiary of DHS Technologies LLC, serving as the global provider of soft walled shelter technology.

For more than 25 years, DHS Technologies and its subsidiaries have been leaders of mobile infrastructure technology – aiding military, medical, government and civilian agencies around the globe. Through continued ingenuity, DHS Systems International commits to developing the best products for its customers.

Among the many products available through DHS is the company’s core product, the Deployable Rapid Assembly Shelter (DRASH). DRASH is a quick set-up/strike soft walled shelter specifically designed for mobility and rapid deployment.  DRASH Shelters come in a variety of makes and models, fulfilling the diverse needs of its customers.

DHS also offers Utility Support Trailers (UST), DRASH Accessories and other technology for use in conjunction with the DRASH Shelter Systems.

To learn more about DRASH products, please visit our website at www.drash.com

Featured Products:

J Series Side Mounted Large Screen Display Systems

This quarter’s featured product is the J Series Side Mounted Large Screen Display System. It is the newest addition to the DRASH Deployable Command and Control Equipment.

The purpose of the J Series Side Mounted Large Screen Display System is to increase mobility throughout DRASH shelters by eliminating the need to set up DC2E along the shelters' width. Instead, the new Side Display System posts on the shelters' length. Such a design enables personnel and equipment to move freely throughout the length of a DRASH shelter without restriction. The new design also allows military personnel to connect various shelters as needed to increase the size of the overall system.

Rapid Military Deployable Shelter Systems

DRASH Deployable Rapid Assembly Shelters are the epitome of quick and efficient soft walled technology. Superior protective elements and reliable features are what make these shelters so functional and unique. All shelters are rapidly deployable and structured with an advanced, highly flexible composite material called Titanite®. The shelter’s frame is comprised of pairs of Titanite® struts that connect at key points in the framework called hubs. These hubs allow for rapid deployment, as they enable the entire shelter to be pushed up and out swiftly without additional assembly.  The shelter comes pre-attached with a double layer of Xytex, a high-tech fabric that provides insulation from hot and cold temperatures.  The specially coated fabric is fire retardant, water repellant and resistant to mildew, abrasion and ultraviolet rays.

DRASH Shelters come in a variety of sizes and divide into separate categories according to their width.  Beginning with the smallest C Series shelter, at 109 square ft. (2.3 meters) and ending with the largest J Series shelter, at 1,250 square ft. (116 meters), the range in size accommodates a diversity of client needs.  In addition, every shelter is easily connectable to any other shelter regardless of the series or model.
A key component to the DRASH Shelter System is the Utility Support Trailer (UST).  A UST is an integrated support system designed to provide mobility, power and or environmental control for all DRASH shelters.  USTs come in various models, tailoring to the energy needs of every mission. Depending on the model, a UST comes equipped with a generator and/or ECU. Models that are equipped with ECUs enable the shelters to function in harsh climates. Some trailers incorporate a new energy efficient Intelligent Power Technology (IPT), while other trailers have traditional analog systems.  All trailers are operable in rough terrain, and are easily towable by military vehicles.
Every element within a DRASH Shelter System has undergone rigorous testing to meet all Military Standard Requirements.

Intelligent Power Technology™ - IPT

Interconnectable Trailer-Mounted Generators

Intelligent Power Technology (IPT) is a reflection of DHS’s effort toward creating energy efficient products. The DRASH IPT enables users to interconnect various trailer-mounted generators to form a micro grid of networked power.

When activated, each generator responds to real time power demands. The system is self-adjusting but users have the ability to monitor activity from inside the Tactical Operations Center.  Because IPT responds to the user’s power needs, it eliminates wasted energy expenditure in unoccupied areas of the shelter. Having, IPT reduces unused energy, which ultimately minimizes unnecessary fuel costs.

Deployable Command and Control Equipment (DC2E)

DRASH Deployable Command and Control Equipment (DC2E) encompasses projector systems, audio visual switching systems and system accessories , all designed to facilitate information management on the battlefield.

DC2E equipment is portable and lightweight so setting up and dismantling requires minimal time and few personnel.  Front/Rear Projection Systems are available with Medium, Large, and now Side Mounted Screen Displays. Audio Visual Systems include Mini, Small, Medium and Large variants.  An Intelligent Data Distribution System, Microphone System, Clock System, IPT Remote Monitor and Tactical Utility Field Furniture are additional accessories that complete the DC2E line.

Accessories:

DRASH Accessories enhance the client’s experience within a DRASH Shelter.

All accessories allow for easy installment so military personnel can perform assembly without outside guidance. However, DRASH field representatives are available for onsite support should one require it.
DRASH Accessories include the following items:

• D- 1000B Heater
• DrashLite
• DRASH Boot
• Shelter Anchor Bag
• Power Distribution Units (PDU)
• Shelter Electrical Kit
• Trailer Deployment Package
• Shelter Spare Parts Kit
• Connector Sets
• Extreme Weather Kit
• Plenum
• Turf Cart
• Hard Door

Applications:

DHS Systems International provides solutions to address the varying missions and requirements relevant to today’s military and first responders.

That is why DHS continues to research and develop new applications for its products.  Among the many possible footprints, the applications listed below are the most prevalent:

• Command and Control
• Medical
• Life Support Areas
• Maintenance
• Unmanned Aerial Vehicle Shelter Systems
• Satellite Support Systems
• Homeland Response Force
• Mortuary
